Locating the 360 Degree Cameras

Rear View Camera

The rear view camera is on the liftgate. It provides a video image of the area behind your vehicle.

Front View Camera

The front view camera is in the grille. It provides a video image of the area in front of your vehicle. To use the front camera system, place the transmission in any gear except reverse (R) and press the camera icon in the corner of the screen.

Side View Camera

The side view camera is on the outside mirror. It provides a video image of the area on the sides of your vehicle to aid you when parking.

360 Degree Camera Guide Lines

Note: Active guide lines are only available when the transmission is in reverse (R).

Lincoln Nautilus. Locating the 360 Degree Cameras. 360 Degree Camera Guide Lines

  1. Active guide lines.
  2. Centerline.
  3. Fixed guide line: Green zone.
  4. Fixed guide line: Yellow zone.
  5. Fixed guide line: Red zone.
  6. Rear bumper.

Active guide lines only show with fixed guide lines. Turn the steering wheel to point the guide lines toward an intended path. If the steering wheel position changes when reversing, your vehicle could deviate from the intended path.

The fixed and active guide lines fade in and out depending on the steering wheel position. The active guide lines do not display when the steering wheel position is straight.

Objects in the red zone are closest to your vehicle and objects in the green zone are farther away. Objects get closer to your vehicle as they move from the green zone to the yellow or red zones. Use the side view mirrors and rear view mirror to get better coverage on both sides and rear of your vehicle.

Keep Out Zone

Lincoln Nautilus. Locating the 360 Degree Cameras. 360 Degree Camera Guide Lines

The Keep Out Zone is represented by the yellow dotted lines running parallel to your vehicle.
